所属品牌：阿特拉斯·科普柯atlas copco
产品型号：etv/etp/etc st系列
atlas阿特拉斯tensor st 电动扳手，是一款在性能和操作舒适性之间平衡把握得很优秀的产品。阿特拉斯tensor st 电动扳手采用的是轻量化设计路线，配上阿特拉斯独有的tensor 马达和高速扳手，可以大幅度的降低拧紧周期时间。同样的这款st电动扳手具有拧紧反馈功能，可以在保证安全的前提下有效的提高作业效率、装配质量。
- 商品描述
- 商品询价热度
atlas阿特拉斯tensor st 电动扳手
阿特拉斯atlas电动扳手tensor st 优势特点
高速扳手
智能机载附件
优异的操作员舒适性
提高装配质量和安全
清晰、精准的操作员反馈
集成可配置 led 和扬声器
重量轻，握把设计符合人体工学
更快的过程时间极大提高工作效率
atlas电动扳手tensor st 各型号技术参数
| title | id | 型号类型 | 扭矩范围值 | 扭矩范围值 | 重量 | 速度 | 方头驱动器 | 长度 | cs 距离 | 声压 | 声音标准 | 经过 ccc 认证 | kc id | 经过 kc 认证 | 经过 eac 认证 | 电机电压类型 | ec 标准 | 电机功率 | 电机电压 | 张量 | weee | eu 指令 | 花键/安装 | 高度 | 震动值 | 震动标准 | a | a/f | b | c | d | e | f | g | h | j | r | r1 | tube nut type | front part interface | 扣爪类型 | 附加声音值 | 附加振动值 | f1 | 电池 | cmiit id | 通信类型 | etl 控制编号 | etl listed | etl 文本 | fcc id | 空转速度 9.6 v | ic id |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| etd st81-120-13 | 8433216025 | straight | 91 ft lb | 19 ft lb | 5.5 lb | 505 r/min | 1/2 inch | 510 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 2 / 2 | ||||||||||||||||||||||||||||||
| etv st101-1500-38-tm | 8433208470 | angle | 1100 ft lb | 240 ft lb | 42 lb | 48 r/min | 1 1/2 inch | 719 mm | 71 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 233 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-1000-tm | 8433208405 | angle | 734 ft lb | 184 ft lb | 24.3 lb | 77 r/min | 1 inch | 679 mm | 40 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 191 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| eto st81-100-24-li3 | 8433231198 | tube nut | 81 ft lb | 28 ft lb | 10.1 lb | 240 r/min | 706 mm | <70 db(a) | iso15744 | r-rei-50a-etvst81 | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1300 w | 200 v | st | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | 46 mm | 24 mm | 20 mm | 16 mm | 71.3 mm | 50.6 mm | 160.4 mm | 64 mm | 77 mm | 20.5 mm | 33 mm | 24.6 mm | in-line | ||||||||||||||||||||
| etd st101-4000-38-s-f | 8433219740 | straight | 2950 ft lb | 735 ft lb | 48 lb | 25 r/min | 1 1/2 inch | 823 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | ||||||||||||||||||||||||||||||
| etv st61-99-13 | 8433203880 | angle | 73 ft lb | 15 ft lb | 5.1 lb | 362 r/min | 482 mm | 20 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst61-70-13 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||
| etv st101-200-20-f | 8433208093 | angle | 147 ft lb | 37 ft lb | 9.7 lb | 485 r/min | 3/4 inch | 602 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-370-20-f | 8433208248 | angle | 273 ft lb | 66 ft lb | 16.1 lb | 280 r/min | 3/4 inch | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 62 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-200-f-had | 8433230221 | pistol | 145 ft lb | 45 ft lb | 11.5 lb | 396 r/min | 0/0 inch | 300 mm | 32.5 mm | <70 db(a) | iso15744 | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | n/a | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st101-2000-38-tm | 8433208480 | angle | 1475 ft lb | 370 ft lb | 42 lb | 35 r/min | 1 1/2 inch | 719 mm | 71 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 231 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-6500-38-f-ha | 8433232703 | pistol | 4794 ft lb | 1438 ft lb | 29.3 lb | 12.4 r/min | 1 1/2 inch | 451 mm | 51 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | wave 72 | <2.5 m/s² | iso28927-1 | ||||||||||||||||||||||||||||
| etv st101-100-had | 8433208045 | angle | 74 ft lb | 15 ft lb | 10.8 lb | 920 r/min | 572 mm | 23 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 71.4 mm | <2.5 m/s² | iso28927-2 | 100 had | ||||||||||||||||||||||||||||
| etv st81-180-13 | 8433206231 | angle | 133 ft lb | 26 ft lb | 7.0 lb | 310 r/min | 1/2 inch | 555 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 65 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-600-25 | 8433208356 | angle | 443 ft lb | 111 ft lb | 23.4 lb | 151 r/min | 1 inch | 715 mm | 54.0 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 76 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-500-20-f | 8433218330 | straight | 368 ft lb | 88 ft lb | 18.5 lb | 204 r/min | 3/4 inch | 717 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etc st101-80-13sf-li4 | 8433232433 | crowfoot | 60 ft lb | 26 ft lb | 10.8 lb | 1013 r/min | 869.5 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etv st81-180-13-intel | 8433206280 | angle | 133 ft lb | 26 ft lb | 310 r/min | 1/2 inch | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etd st101-500-20-t40-f | 8433218349 | straight | 368 ft lb | 88 ft lb | 18.5 lb | 204 r/min | 3/4 inch | 769 mm | 37 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-1000-tm-f | 8433208410 | angle | 734 ft lb | 184 ft lb | 24.3 lb | 77 r/min | 1 inch | 679 mm | 40 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 191 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-150-13-t25-s | 8433218175 | straight | 109 ft lb | 22 ft lb | 16.5 lb | 685 r/min | 1/2 inch | 656 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 6 | ||||||||||||||||||||||||||||||
| etd st81-120-13-t25 | 8433215953 | straight | 91 ft lb | 19 ft lb | 5.8 lb | 505 r/min | 1/2 inch | 538 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 3 / 5 | ||||||||||||||||||||||||||||||
| etv st101-180-13 | 8433208052 | angle | 133 ft lb | 37 ft lb | 9.3 lb | 575 r/min | 1/2 inch | 600 mm | 25.3 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etc st81-60-14-li3 | 8433232296 | crowfoot | 44 ft lb | 16 ft lb | 880 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | in-line | |||||||||||||||||||||||||||||||||
| etv st101-370-intel | 8433208240 | angle | 273 ft lb | 82 ft lb | 18.5 lb | 280 r/min | 3/4 inch | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 113 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-100-had | 8433205636 | angle | 80 ft lb | 15 ft lb | 540 r/min | 1/2 inch | 522 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | 100 had | ||||||||||||||||||||||||||||||
| etv st101-370-fs | 8433208238 | angle | 273 ft lb | 66 ft lb | 16.5 lb | 280 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 77 mm | <2.5 m/s² | iso28927-2 | 370 fs | ||||||||||||||||||||||||||||
| etv st81-180-had | 8433206260 | angle | 133 ft lb | 26 ft lb | 7.0 lb | 310 r/min | 560 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etv st101-180-had | 8433208088 | yes | r-rei-50a-etvst101 | yes | 1500 w | 4 - large equipment >50cm | |||||||||||||||||||||||||||||||||||||||||||||||
| etv st81-180-b13 | 8433206243 | angle | 133 ft lb | 26 ft lb | 7.0 lb | 310 r/min | 1/2 inch | 555 mm | 25.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 65 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-500-20 | 8433218328 | straight | 368 ft lb | 88 ft lb | 18.5 lb | 204 r/min | 3/4 inch | 717 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-4000-38-tm-f | 8433208490 | angle | 2950 ft lb | 834 ft lb | 47 lb | 21.8 r/min | 1 1/2 inch | 710 mm | 71 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | 2004/108/ec, 2006/42/ec, 2006/95/ec | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 350 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-100-13 | 8433217900 | straight | 73 ft lb | 18 ft lb | 7.0 lb | 1043 r/min | 1/2 inch | 631 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st32-20-10 | 8433221695 | pistol | 15.0 ft lb | 3.6 ft lb | 2 lb | 677 r/min | 3/8 inch | 235 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st101-270-20-m | 8433208182 | angle | 199 ft lb | 48 ft lb | 18.8 lb | 380 r/min | 3/4 inch | 763 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | 62 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-1500-25-tm-f | 8433208465 | angle | 1106 ft lb | 240 ft lb | 26 lb | 23 r/min | 1 inch | 625 mm | 43 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 257 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-50-had | 8433205280 | angle | 40 ft lb | 12 ft lb | 5.0 lb | 1090 r/min | 473 mm | 18.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80 mm | <2.5 m/s² | iso28927-2 | 50 had | ||||||||||||||||||||||||||||
| etp st101-8000-38-f-ha | 8433232803 | pistol | 5900 ft lb | 1770 ft lb | 29.3 lb | 10 r/min | 1 1/2 inch | 451 mm | 51 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | wave 72 | <2.5 m/s² | iso28927-1 | ||||||||||||||||||||||||||||
| etp st101-300-20-f | 8433230302 | pistol | 221 ft lb | 66 ft lb | 11.5 lb | 293 r/min | 3/4 inch | 303 mm | 32.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 3 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-150-20-f | 8433218140 | straight | 109 ft lb | 22 ft lb | 9.3 lb | 685 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-70-13 | 8433205348 | angle | 58 ft lb | 15 ft lb | 5.0 lb | 790 r/min | 1/2 inch | 485 mm | 20 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-450-20-f | 8433208290 | angle | 332 ft lb | 81 ft lb | 23.4 lb | 230 r/min | 3/4 inch | 715 mm | 54 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 76 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| eto st101-290-60-lo3 | 8433232376 | crowfoot | 232 ft lb | 47 ft lb | 24.8 lb | 230 r/min | 779 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | offset | |||||||||||||||||||||||||||||||
| etd st81-90-13-t25 | 8433215725 | straight | 70 ft lb | 15 ft lb | 5.8 lb | 675 r/min | 1/2 inch | 538 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 3 / 5 | ||||||||||||||||||||||||||||||
| etd st101-200-20-t40-f | 8433218245 | straight | 146 ft lb | 36 ft lb | 16.5 lb | 500 r/min | 3/4 inch | 756 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st101-4000-38-t50f | 8433218742 | straight | 2950 ft lb | 735 ft lb | 48 lb | 25 r/min | 1 1/2 inch | 921 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-180-b13 | 8433208056 | angle | 133 ft lb | 37 ft lb | 9.3 lb | 575 r/min | 1/2 inch | 600 mm | 25 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-200-20-t25 | 8433218215 | straight | 146 ft lb | 36 ft lb | 16.3 lb | 500 r/min | 3/4 inch | 743 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-370-20 | 8433208226 | angle | 273 ft lb | 66 ft lb | 16.1 lb | 280 r/min | 3/4 inch | 672 mm | 32.9 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 62 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-200-had-f | 8433208104 | angle | 147 ft lb | 37 ft lb | 11.2 lb | 485 r/min | 602 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80.2 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etv st101-600-25-f | 8433208369 | angle | 443 ft lb | 111 ft lb | 23.4 lb | 150 r/min | 1 inch | 715 mm | 54 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 76 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-200-fs | 8433206459 | angle | 154 ft lb | 30 ft lb | 7.0 lb | 300 r/min | 557 mm | 28 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | 200 fs | ||||||||||||||||||||||||||||
| etp st32-10-i06-bcr | 8433221473 | pistol | 8.0 ft lb | 2.2 ft lb | 2.1 lb | 1210 r/min | 1/4 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 205 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etc st81-120-15-li3 | 8433232048 | crowfoot | 88.4 ft lb | 20.6 ft lb | 9.4 lb | 357 r/min | 703 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | iso11148-6:2010 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec | <2.5 m/s² | iso28927-2 | 19 mm | in-line | |||||||||||||||||||||||||||||
| etd st101-200-20 | 8433218205 | straight | 146 ft lb | 36 ft lb | 16.3 lb | 500 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st101-750-25-f | 8433230752 | pistol | 550 ft lb | 160 ft lb | 13.7 lb | 132 r/min | 1 inch | 353 mm | 33.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 5 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-50-10-f | 8433205160 | angle | 40 ft lb | 12 ft lb | 3.9 lb | 1090 r/min | 3/8 inch | 473 mm | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 48 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||
| etv st101-270-intel | 8433208140 | angle | 199 ft lb | 48 ft lb | 18.5 lb | 380 r/min | 3/4 inch | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 113 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-150-20-t25 | 8433218143 | straight | 109 ft lb | 22 ft lb | 9.5 lb | 685 r/min | 3/4 inch | 741 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | etd st101-150-20-t25 | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etc st81-136-17-lo5 | 8433232356 | crowfoot | 100 ft lb | 23 ft lb | 7.7 lb | 217 r/min | 712 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etp st101-2400-25-f-ha | 8433232603 | pistol | 1770 ft lb | 531 ft lb | 16.5 lb | 31.7 r/min | 1 inch | 399.6 mm | 35 mm | 74 db(a) | iso15744 | no | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | wave 47 | <2.5 m/s² | iso28927-1 | ||||||||||||||||||||||||||||
| etv st101-450-20-sh | 8433208279 | angle | 332 ft lb | 81 ft lb | 230 r/min | 3/4 inch | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etd st101-120-13-t25-f | 8433218048 | straight | 88 ft lb | 22 ft lb | 7.3 lb | 873 r/min | 1/2 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-100-b13 | 8433205824 | angle | 80 ft lb | 15 ft lb | 5.9 lb | 540 r/min | 1/2 inch | 522 mm | 22.5 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 60 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-200-20 | 8433208092 | angle | 147 ft lb | 37 ft lb | 9.7 lb | 485 r/min | 3/4 inch | 602 mm | 27.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-300-20-f | 8433218272 | straight | 221 ft lb | 51 ft lb | 16.3 lb | 345 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-500-20-sh | 8433208265 | angle | 370 ft lb | 75 ft lb | 16.1 lb | 140 r/min | 3/4 inch | 670 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 85 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-70-13-f | 8433205355 | angle | 58 ft lb | 15 ft lb | 5.0 lb | 790 r/min | 1/2 inch | 485 mm | 20 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-2000-38-s-f | 8433219722 | straight | 1475 ft lb | 370 ft lb | 37 lb | 48 r/min | 1 1/2 inch | 742 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | ||||||||||||||||||||||||||||||
| etv st81-70-fs | 8433205508 | angle | 58 ft lb | 15 ft lb | 5.0 lb | 790 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | 70 fs | |||||||||||||||||||||||||||||||
| etp st32-05-i06 | 8433221219 | pistol | 3.6 ft lb | 0.7 ft lb | 1.7 lb | 2820 r/min | 1/4 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st101-180-had | 8433208089 | angle | 133 ft lb | 37 ft lb | 10.8 lb | 575 r/min | 600 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80.1 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etp st101-4000-25-f-ha | 8433232403 | pistol | 2950 ft lb | 885 ft lb | 24.5 lb | 16 r/min | 1 inch | 464 mm | 42 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | wave 70 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-2000-38t50sf | 8433219720 | straight | 1475 ft lb | 370 ft lb | 37 lb | 48 r/min | 1 1/2 inch | 840 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | ||||||||||||||||||||||||||||||
| etc st81-140-15hbh-lo5 | 8433232413 | crowfoot | 103 ft lb | 21 ft lb | 10.6 lb | 300 r/min | 675 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | offset | |||||||||||||||||||||||||||||||
| etv st101-100-intel | 8433208028 | angle | 74 ft lb | 15 ft lb | 10.2 lb | 920 r/min | 1/2 inch | 572 mm | 23 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 82 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-1200-25-s | 8433219610 | straight | 885 ft lb | 220 ft lb | 26 lb | 81 r/min | 1 inch | 787 mm | 47 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 7 | ||||||||||||||||||||||||||||||
| etv st81-100-13 | 8433205682 | angle | 80 ft lb | 15 ft lb | 5.9 lb | 540 r/min | 1/2 inch | 522 mm | 22.5 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 60 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-2000-38-f | 8433232202 | pistol | 1475 ft lb | 442 ft lb | 25.4 lb | 38 r/min | 1 1/2 inch | 454 mm | 48 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61000-6-2:2005, en 61000-6-4:2007 a1:2011/ac:2012, en 61010-1, en 55014-1:2017, en 55014-2:2015 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 7 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-150-13 | 8433206012 | angle | 117 ft lb | 22 ft lb | 7.0 lb | 380 r/min | 1/2 inch | 555 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 65 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-100-13-t25 | 8433217910 | straight | 73 ft lb | 18 ft lb | 7.3 lb | 1043 r/min | 1/2 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st101-100-13-t25-f | 8433217915 | straight | 73 ft lb | 18 ft lb | 7.3 lb | 1043 r/min | 1/2 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etc st81-80-14-e5-lo3 | 8433231849 | crowfoot | 59 ft lb | 11.8 ft lb | 540 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | offset | ||||||||||||||||||||||||||||||||
| etd st101-120-13 | 8433218022 | straight | 88 ft lb | 22 ft lb | 7.0 lb | 875 r/min | 1/2 inch | 631 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-270-20 | 8433208123 | angle | 199 ft lb | 48 ft lb | 16.1 lb | 380 r/min | 3/4 inch | 672 mm | 32.9 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 62 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-600-had | 8433208390 | angle | 443 ft lb | 111 ft lb | 25.8 lb | 150 r/min | 715 mm | 54 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 104.2 mm | <2.5 m/s² | iso28927-2 | 600 had | ||||||||||||||||||||||||||||
| etv st101-370-had | 8433208255 | angle | 273 ft lb | 66 ft lb | 18.3 lb | 280 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 103.5 mm | <2.5 m/s² | iso28927-2 | 370 had | ||||||||||||||||||||||||||||
| etd st101-1200-25t50sf | 8433219612 | straight | 885 ft lb | 220 ft lb | 26 lb | 81 r/min | 1 inch | 844 mm | 47 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 7 | ||||||||||||||||||||||||||||||
| etc st101-200-22-lo5 | 8433232362 | crowfoot | 151.9 ft lb | 38.3 ft lb | 280 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 300328:2007, en 60745-1, en 60745-2-2, en 61000-6-2:2005, en 61000-6-4:2007 | 1500 w | 200 v | st101 | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu, 2014/53/eu | <2.5 m/s² | iso28927-2 | offset | ||||||||||||||||||||||||||||||||
| etd st101-300-20-t40 | 8433218282 | straight | 221 ft lb | 51 ft lb | 16.5 lb | 345 r/min | 3/4 inch | 756 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-50-10 | 8433205155 | angle | 40 ft lb | 12 ft lb | 3.9 lb | 1090 r/min | 3/8 inch | 473 mm | 18 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 48 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st81-90-13 | 8433215814 | straight | 70 ft lb | 15 ft lb | 5.5 lb | 675 r/min | 1/2 inch | 510 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 2 / 2 | ||||||||||||||||||||||||||||||
| etd st101-500-20-t40 | 8433218338 | straight | 368 ft lb | 88 ft lb | 18.5 lb | 204 r/min | 3/4 inch | 768 mm | 37 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st81-70-13-t25 | 8433215498 | straight | 51 ft lb | 12 ft lb | 5.8 lb | 880 r/min | 1/2 inch | 538 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 3 / 5 | ||||||||||||||||||||||||||||||
| etp st101-5500-38-f-ha | 8433232503 | pistol | 4057 ft lb | 1217 ft lb | 29.3 lb | 17 r/min | 1 1/2 inch | 451 mm | 51 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/eu, 2011/65/eu, 2014/30/eu | wave 72 | <2.5 m/s² | iso28927-1 | ||||||||||||||||||||||||||||
| etp st101-4000-38-f | 8433232402 | pistol | 2950 ft lb | 885 ft lb | 33 lb | 20 r/min | 1 1/2 inch | 481 mm | 59 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-200-20-sh | 8433208199 | r-rei-50a-etvst101 | yes | 1500 w | |||||||||||||||||||||||||||||||||||||||||||||||||
| etd st101-120-13-t25 | 8433218032 | straight | 88 ft lb | 22 ft lb | 7.3 lb | 873 r/min | 1/2 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-370-had-f | 8433208258 | angle | 273 ft lb | 66 ft lb | 18.3 lb | 280 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 103.5 mm | <2.5 m/s² | iso28927-2 | 370 had | ||||||||||||||||||||||||||||
| etv st101-200-intel | 8433208101 | angle | 147 ft lb | 37 ft lb | 10.6 lb | 485 r/min | 1/2 inch | 602 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 90 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etc st101-180-19-lo5 | 8433232264 | crowfoot | 132.8 ft lb | 33.9 ft lb | 380 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | offset | ||||||||||||||||||||||||||||||||||
| etv st81-120-13 | 8433205683 | angle | 88 ft lb | 27 ft lb | 6 lb | 470 r/min | 560 mm | 25.5 mm | <70 db(a) | iso15744 | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 65 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||||
| etv st101-200-fs | 8433208096 | angle | 147 ft lb | 37 ft lb | 9.7 lb | 485 r/min | 602 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | 200 fs | ||||||||||||||||||||||||||||
| etv st101-450-had | 8433208297 | angle | 332 ft lb | 81 ft lb | 25.8 lb | 230 r/min | 715 mm | 54 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 104.2 mm | <2.5 m/s² | iso28927-2 | 600 had | ||||||||||||||||||||||||||||
| etd st81-30-10 | 8433215193 | straight | 22 ft lb | 7 ft lb | 4.0 lb | 1700 r/min | 3/8 inch | 450 mm | 24 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | – / 1 | ||||||||||||||||||||||||||||||
| etv st81-70-m75-t25 | 8433205585 | angle | 58 ft lb | 15 ft lb | 12.7 lb | 790 r/min | 1/2 inch | 566 mm | 40 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 196 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-100-13 | 8433208010 | angle | 74 ft lb | 15 ft lb | 9.3 lb | 920 r/min | 1/2 inch | 572 mm | 22.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 44 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-1200-25-f | 8433218610 | straight | 885 ft lb | 220 ft lb | 26 lb | 81 r/min | 1 inch | 787 mm | 47 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-100-b13 | 8433208020 | angle | 74 ft lb | 15 ft lb | 9.3 lb | 920 r/min | 1/2 inch | 572 mm | 23 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 44 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-200-20-f | 8433218210 | straight | 146 ft lb | 36 ft lb | 16.3 lb | 500 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-200-20 | 8433206342 | angle | 154 ft lb | 30 ft lb | 7.0 lb | 300 r/min | 3/4 inch | 556 mm | 27 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 70 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-750-25-t50-f | 8433218469 | straight | 553 ft lb | 109 ft lb | 20.3 lb | 143 r/min | 1 inch | 769 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st31-10-10-bcr | 8433201415 | angle | 8.8 ft lb | 2.2 ft lb | 1020 r/min | 3/8 inch | 381 mm | <70 db(a) | iso15744 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1050 w | 200 v | st | 5 - small equipment <50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||||||
| etd st101-150-20 | 8433218136 | straight | 109 ft lb | 22 ft lb | 9.3 lb | 685 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st32-20-i06-bcr | 8433221726 | pistol | 15.0 ft lb | 3.6 ft lb | 2.3 lb | 677 r/min | 1/4 inch | 237 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 205 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st61-50-10-m75-t15 | 8433203455 | angle | 40 ft lb | 7 ft lb | 5.5 lb | 655 r/min | 3/8 inch | 528 mm | 18.25 mm | <70 db(a) | iso15744 | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | 91 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etd st101-4000-38-f | 8433218740 | straight | 2950 ft lb | 735 ft lb | 48 lb | 25 r/min | 1 1/2 inch | 823 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st101-500-20-f | 8433230502 | pistol | 365 ft lb | 110 ft lb | 13 lb | 186 r/min | 3/4 inch | 334 mm | 33.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 4 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-600-tm-f | 8433208396 | angle | 443 ft lb | 111 ft lb | 16.8 lb | 132 r/min | 3/4 inch | 613 mm | 34 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 143 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-1000-25-f | 8433231002 | pistol | 735 ft lb | 220 ft lb | 14.1 lb | 99 r/min | 1 inch | 364 mm | 33.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 5 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-200-had-f | 8433206510 | angle | 154 ft lb | 30 ft lb | 7.7 lb | 300 r/min | 597 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 91 mm | <2.5 m/s² | iso28927-2 | 200 had | |||||||||||||||||||||||||||||
| etd st101-200-20-t40 | 8433218223 | straight | 146 ft lb | 36 ft lb | 16.5 lb | 500 r/min | 3/4 inch | 756 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st101-1300-20-f-ha | 8433231303 | pistol | 959 ft lb | 288 ft lb | 14.1 lb | 65 r/min | 3/4 inch | 348 mm | 34 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | wave 40 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-2000-38 | 8433218722 | straight | 1475 ft lb | 370 ft lb | 37 lb | 48 r/min | 1 1/2 inch | 742 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp sr31-25-i06 | 8436430021 | pistol | 18.4 ft lb | 3.7 ft lb | 1.8 lb | 2010 r/min | 1/4 inch | 210 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpsr31-20-10 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1400 w | 200 v | sr | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-1 | 85 db(a) | 25 m/s² | |||||||||||||||||||||||||||
| etd st101-500-20-t40-s | 8433218398 | straight | 368 ft lb | 88 ft lb | 17.6 lb | 204 r/min | 3/4 inch | 680 mm | 37 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 6 | ||||||||||||||||||||||||||||||
| etv st81-100-fs | 8433205868 | angle | 80 ft lb | 15 ft lb | 5.9 lb | 540 r/min | 522 mm | 23 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 51 mm | <2.5 m/s² | iso28927-2 | 70 fs | ||||||||||||||||||||||||||||
| etd st101-150-20-t40f | 8433218159 | straight | 109 ft lb | 22 ft lb | 9.7 lb | 685 r/min | 3/4 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-270-had-f | 8433208195 | angle | 199 ft lb | 48 ft lb | 18.3 lb | 380 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | 103.5 mm | <2.5 m/s² | iso28927-2 | 370 had | ||||||||||||||||||||||||||||
| etd st101-750-25-t50 | 8433218456 | straight | 553 ft lb | 109 ft lb | 20.3 lb | 143 r/min | 1 inch | 727 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st32-20-i06 | 8433221711 | pistol | 15.0 ft lb | 3.6 ft lb | 2 lb | 677 r/min | 1/4 inch | 235 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etp st101-1500-25-f | 8433232152 | pistol | 1106 ft lb | 332 ft lb | 19.4 lb | 47 r/min | 1 inch | 402 mm | 43.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 9 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st81-70-13 | 8433215603 | straight | 51 ft lb | 12 ft lb | 5.5 lb | 880 r/min | 1/2 inch | 510 mm | 26.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 2 / 2 | ||||||||||||||||||||||||||||||
| etp st32-05-10 | 8433221103 | pistol | 3.6 ft lb | 0.7 ft lb | 1.7 lb | 2820 r/min | 3/8 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st81-200-had | 8433206509 | angle | 154 ft lb | 30 ft lb | 7.0 lb | 300 r/min | 561 mm | 28 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 81 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etc st101-200-17-lo3 | 8433232076 | crowfoot | 147 ft lb | 33 ft lb | 20.6 lb | 380 r/min | 730.4 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||
| etd st81-50-13 | 8433215334 | straight | 37 ft lb | 12 ft lb | 4.6 lb | 1230 r/min | 1/2 inch | 493 mm | 24 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 2 / 2 | ||||||||||||||||||||||||||||||
| etv st81-180-fs | 8433206250 | angle | 133 ft lb | 26 ft lb | 7.0 lb | 310 r/min | 555 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 58 mm | <2.5 m/s² | iso28927-2 | 200 fs | ||||||||||||||||||||||||||||
| etv st101-100-13-f | 8433208030 | angle | 74 ft lb | 15 ft lb | 9.3 lb | 920 r/min | 1/2 inch | 572 mm | 23 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 44 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st32-10-i06 | 8433221463 | pistol | 8.0 ft lb | 2.2 ft lb | 1.8 lb | 1210 r/min | 1/4 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| eto st61-30-dh14-li3 | 8433231824 | tube nut | 24.3 ft lb | 4.4 ft lb | 5.1 lb | 772 r/min | 544 mm | <70 db(a) | iso15744 | yes | msip-rei-50a-etv-st | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1200 w | 200 v | eto st61-30-dh14-li3 | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | inline | ||||||||||||||||||||||||||||||
| etv st81-150-b13 | 8433206097 | angle | 117 ft lb | 22 ft lb | 7.0 lb | 380 r/min | 1/2 inch | 555 mm | 25.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 65 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-1000-25-t50 | 8433218578 | straight | 737 ft lb | 184 ft lb | 21.6 lb | 100 r/min | 1 inch | 754 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st101-100-13-f | 8433217905 | straight | 73 ft lb | 18 ft lb | 7.0 lb | 1043 r/min | 1/2 inch | 631 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | - | ||||||||||||||||||||||||||||||
| etd st101-1000-25-t50f | 8433218589 | straight | 737 ft lb | 184 ft lb | 21.6 lb | 100 r/min | 1 inch | 755 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st101-1200-25-t50f | 8433218612 | straight | 885 ft lb | 22 ft lb | 26 lb | 81 r/min | 1 inch | 844 mm | 47 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etp st32-05-i06-bcr | 8433221229 | pistol | 3.7 ft lb | 0.7 ft lb | 2 lb | 2820 r/min | 1/4 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 205 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st81-50-10-g | 8433205285 | angle | 51 ft lb | 11 ft lb | 3.9 lb | 654 r/min | 3/8 inch | 473 mm | 18 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 48 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st81-150-had | 8433206181 | angle | 117 ft lb | 22 ft lb | 7.0 lb | 365 r/min | 560 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etv st101-270-had | 8433208192 | angle | 199 ft lb | 48 ft lb | 18.3 lb | 380 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 103.5 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etv st101-450-20 | 8433208281 | angle | 332 ft lb | 81 ft lb | 23.4 lb | 230 r/min | 3/4 inch | 715 mm | 54.0 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 76 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etv st101-180-had-f | 8433208090 | angle | 133 ft lb | 37 ft lb | 10.1 lb | 575 r/min | 600 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80.1 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st101-180-13-f | 8433208063 | angle | 133 ft lb | 37 ft lb | 9.3 lb | 575 r/min | 1/2 inch | 600 mm | 25 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-3000-38-f | 8433232302 | pistol | 2212 ft lb | 664 ft lb | 33 lb | 24 r/min | 1 1/2 inch | 476 mm | 59 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etc-st101-265-18hex-lo4 | 8433232426 | crowfoot | 196 ft lb | 40 ft lb | 17 lb | 1375 r/min | 807 mm | <70 db(a) | iso15744 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||||||
| etd st101-750-25 | 8433218440 | straight | 553 ft lb | 109 ft lb | 20.3 lb | 143 r/min | 1 inch | 681 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-270intel-t50 | 8433208126 | angle | 199 ft lb | 48 ft lb | 16.5 lb | 380 r/min | 675 mm | 35.9 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 4 - large equipment >50cm | 2004/108/ec, 2006/42/ec, 2006/95/ec | 235 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||||
| etd st101-1000-25 | 8433218560 | straight | 737 ft lb | 184 ft lb | 21.6 lb | 100 r/min | 1 inch | 708 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-120-had | 8433205865 | angle | 100 ft lb | 22 ft lb | 6.0 lb | 540 r/min | 560 mm | 26 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 80 mm | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||
| etd st101-150-20-t40 | 8433218146 | straight | 109 ft lb | 22 ft lb | 9.7 lb | 685 r/min | 3/4 inch | 656 mm | 30.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etc st81-70-15-lo5 | 8433231826 | crowfoot | 51.6 ft lb | 10.5 ft lb | 380 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | offset | ||||||||||||||||||||||||||||||||
| etc st101-200-22-lo3 | 8433231057 | crowfoot | 147 ft lb | 38 ft lb | 20.5 lb | 380 r/min | 738 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | 139.8 mm | 22 mm | 37 mm | 38.55 mm | 76.2 mm | 98.7 mm | 132.7 mm | 75.3 mm | 45 mm | 22.5 mm | offset | 135.5 mm | |||||||||||||||||||
| etv st101-240-20-sh-l300 | 8433208197 | angle | 177 ft lb | 53 ft lb | 24 lb | 280 r/min | 3/4 inch | 1096 mm | 27.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 47 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st101-200-20-f | 8433230202 | pistol | 145 ft lb | 45 ft lb | 11.5 lb | 396 r/min | 3/4 inch | 303 mm | 32.5 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etpst101 | yes | yes | 3 a.c. | en 61010-1, en 61000-3-2:2014, en 61000-3-3:2013, en 61000-6-2:2005, en 61000-6-3:2007 a1:2011/ac:2012 | 1500 w | 200 v | st revo | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 3 | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etc st81-90-17ls-li4 | 8433232337 | crowfoot | 66 ft lb | 12 ft lb | 8.7 lb | 1168 r/min | 705 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | in-line | ||||||||||||||||||||||||||||||
| etv st101-600-tm | 8433208362 | angle | 443 ft lb | 111 ft lb | 16.8 lb | 132 r/min | 3/4 inch | 613 mm | 34 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 143 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etd st101-1000-25-f | 8433218570 | straight | 737 ft lb | 184 ft lb | 21.6 lb | 100 r/min | 1 inch | 708 mm | 45 mm | <70 db(a) | iso15744 | r-rei-50a-etvst101 | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 2004/108/ec, 2006/42/ec, 2006/95/ec | - | |||||||||||||||||||||||||||||||||
| etd st101-300-20 | 8433218270 | straight | 221 ft lb | 51 ft lb | 16.3 lb | 345 r/min | 3/4 inch | 706 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st81-100-had-hd | 8433205635 | angle | 80 ft lb | 15 ft lb | 540 r/min | <70 db(a) | iso15744 | yes | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | 200 had | ||||||||||||||||||||||||||||||||
| etd st101-4000-38t50sf | 8433219742 | straight | 2950 ft lb | 735 ft lb | 48 lb | 25 r/min | 1 1/2 inch | 921 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 8 | ||||||||||||||||||||||||||||||
| etv st101-270-fs | 8433208135 | angle | 199 ft lb | 48 ft lb | 16.4 lb | 380 r/min | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 77 mm | <2.5 m/s² | iso28927-2 | 370 fs | ||||||||||||||||||||||||||||
| etd st101-750-25-f | 8433218450 | straight | 553 ft lb | 109 ft lb | 20.3 lb | 143 r/min | 1 inch | 681 mm | 45 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etc st101-200-21-lo3 | 8433231051 | crowfoot | 158 ft lb | 38 ft lb | 20.5 lb | 380 r/min | 731 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | <2.5 m/s² | iso28927-2 | 148.8 mm | 21 mm | 40 mm | 32.75 mm | 70.4 mm | 91.4 mm | 125.4 mm | 75.3 mm | 42 mm | 21 mm | offset | 128.2 mm | |||||||||||||||||||
| etv st101-270-20-f | 8433208145 | angle | 199 ft lb | 48 ft lb | 16.1 lb | 380 r/min | 3/4 inch | 672 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 62 mm | <2.5 m/s² | iso28927-2 | ||||||||||||||||||||||||||||
| etp st32-10-10 | 8433221348 | pistol | 8.0 ft lb | 2.2 ft lb | 1.8 lb | 1210 r/min | 3/8 inch | 197 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1400 w | 200 v | st | 5 - small equipment <50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 179 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etv st81-100-had-tx | 8433205637 | angle | 80 ft lb | 15 ft lb | 5.9 lb | 540 r/min | 522 mm | 22.5 mm | <70 db(a) | iso15744 | r-rei-50a-etvst81 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | 6 - electrical and electronic tools | 2006/42/ec, 2011/65/eu, 2014/30/eu | 60 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||||
| etv st101-600-fs | 8433208364 | angle | 443 ft lb | 111 ft lb | 22.0 lb | 150 r/min | 715 mm | 54 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 69 mm | <2.5 m/s² | iso28927-2 | 600 fs | ||||||||||||||||||||||||||||
| etd st101-300-20-t40-f | 8433218291 | straight | 221 ft lb | 51 ft lb | 16.5 lb | 345 r/min | 3/4 inch | 756 mm | 33 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etd st101-2000-38-t50f | 8433218720 | straight | 1475 ft lb | 370 ft lb | 37 lb | 48 r/min | 1 1/2 inch | 840 mm | 68 mm | <70 db(a) | iso15744 | yes | r-rei-50a-etvst101 | yes | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | - | ||||||||||||||||||||||||||||||
| etv st101-100-fshad-t12 | 8433208081 | angle | 74 ft lb | 15 ft lb | 9.3 lb | 565 r/min | 570 mm | 23 mm | <70 db(a) | iso15744 | yes | na | no | yes | 3 a.c. | en 61000-3-2:2006, en 61000-3-3:2008, en 61000-6-2:2005, en 61000-6-3:2007, en 61010-1 | 1500 w | 200 v | st | 4 - large equipment >50cm | 2006/42/ec, 2011/65/eu, 2014/30/eu | 77 mm | <2.5 m/s² | iso28927-2 | |||||||||||||||||||||||||||||
| etc stb63-40-3/8-lo3-w | 8433232486 | crowfoot | 29 ft lb | 9 ft lb | 8.2 lb | 559 mm | <70 db(a) | iso15744 | no | yes | en 300 328 v2.1.1, en 300 440 v2.1.1, en 301 489-1 v2.1.1, en 301 489-17 v3.1.1, en 55014-1:2017, en 55014-2:2015, en 61000-6-2:2005 ac:2005, en 61000-6-4:2007 a1:2011, en 62841-1:2015, en 62841-2-2:2014 ac:2015 | 1500 w | 30 v | 4 - large equipment >50cm | 2014/53/eu, 2014/30/eu, 2006/42/ec, 2011/65/eu | <2.5 m/s² | iso28927-2 | li-io 30 v | 2014aj1502 | w-lan | 3008099 | yes | 1 - 60745-1, -2-2 | pvh0946 | 365 r/min | 5325a-0946 |
atlas电动扳手etd st81-120-13结构图
今日已有 0018 人询价
相关商品
— related product —
发送邮件
商品评价
13701731174
亚博安卓下载 copyright © 2015 thinkfon. all rights reserved.思奉工业亚博安卓下载的版权所有
icp备案 : |
