所属品牌：阿特拉斯·科普柯atlas copco

产品型号：ltd13/28/38/48

atlas阿特拉斯气动直柄扳手可以给您带来超高工作效率和的扭矩精度。atlas ltd13/28/38/48直柄扳手采用 ltv 角向扳手的动力系统和离合器。可以实现快速旋入和准确的拧紧，大大的提升了生产效率。并且阿特拉斯直柄扳手采用了花键反作用杆连接技术，可以实现扳手的固定装配。

商品描述
商品询价热度

atlas阿特拉斯气动直柄扳手ltd13/28/38/48

气动直柄扳手

atlas ltd气动直柄扳手特点

快速旋入节约时间

大功率马达

空气信号输出指示操作完成

提供您需要的选项，满足您的要求

超高工作效率和的精度

高扭矩准确度

超薄设计实现稳定、简洁的多轴设计

阿特拉斯atlas ltd气动直柄扳手各型号的技术参数

title	id	螺栓尺寸	方头驱动器	扭矩范围软接头值>	扭矩范围软接头值<	空载速度	重量	长度	cs 距离	空转速度下的空气消耗量	推荐的软管尺寸	进气口螺纹	声压	声音标准	经过 eac 认证	ec 标准	工作压力<	断气式	声音不确定度	eu 指令	声功率	atex	atex 代码
ltd38 n30f-re	8431053538	m8 mm	1/2 inch	10 ft lb	21 ft lb	820 r/min	5.0 lb	521 mm	20 mm	42 cfm	10 mm	1/4 inch	79 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r32f-rr	8431070432	m8 mm	1/2 inch	13 ft lb	24 ft lb	560 r/min	5.5 lb	482 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r20-re	8431053451	m6-8 mm	3/8 inch	7 ft lb	15 ft lb	520 r/min	2.9 lb	383 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r8-rr	8431070380	m5-6 mm	3/8 inch	2 ft lb	6 ft lb	1100 r/min	2.6 lb	294 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6		yes	3 db(a)	2006/42/ec
ltd38 n30-re	8431053504	m8 mm	1/2 inch	10 ft lb	21 ft lb	820 r/min	4.8 lb	414 mm	20 mm	34 cfm	10 mm	1/4 inch	79 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r16f-50-rr	8431070381	m8 mm	3/8 inch	6 ft lb	12 ft lb	610 r/min	4 lb	446 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744		iso11148-6	102 psi	yes	3 db(a)	2006/42/ec
ltd38 n44f-re	8431053531	m8-10 mm	1/2 inch	13 ft lb	32 ft lb	580 r/min	5.0 lb	521 mm	20 mm	42 cfm	10 mm	1/4 inch	79 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 n21f-re	8431053439	m6 mm	3/8 inch	7 ft lb	15 ft lb	570 r/min	3.5 lb	466 mm	20 mm	19 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd48 r81-re	8431063712	m12 mm	1/2 inch	24 ft lb	60 ft lb	320 r/min	6.8 lb	582 mm	30 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	95 db(a)
ltd48 r65-re	8431063707	m10 mm	1/2 inch	20 ft lb	48 ft lb	400 r/min	6.8 lb	582 mm	30 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	95 db(a)
ltd38 r32-re	8431053452	m8 mm	1/2 inch	13 ft lb	24 ft lb	560 r/min	4.6 lb	441 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd38 r38-re	8431053578	m8-10 mm	1/2 inch	14 ft lb	28 ft lb	480 r/min	4.6 lb	441 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd38 r27f-re	8431053565	m8 mm	1/2 inch	10 ft lb	20 ft lb	670 r/min	5.5 lb	546 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd38 r27-re	8431053453	m8 mm	1/2 inch	10 ft lb	20 ft lb	670 r/min	4.6 lb	441 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd48 r81f-re	8431063723	m12 mm	1/2 inch	24 ft lb	60 ft lb	320 r/min	7.7 lb	700 mm	30 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	95 db(a)
ltd28 r22-re	8431053454	m6-8 mm	3/8 inch	7 ft lb	16 ft lb	125 r/min	2.9 lb	383 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r40-atex	8431053460	m10 mm	1/2 inch			175 r/min	4.8 lb	453 mm		34 cfm		1/4 inch	82 db(a)	iso15744	yes	en 13463-1:2009, iso 11148-6	100 psig	yes	3 db(a)	2006/42/ec, 2014/34/eu	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltd48 r65f-rr	8431070450	m10 mm	1/2 inch	20 ft lb	48 ft lb	400 r/min	8.2 lb	522 mm	28 mm	63 cfm	12.5/16 mm		80 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r16-re	8431053465	m6 mm	3/8 inch	6 ft lb	12 ft lb	610 r/min	2.9 lb	383 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 n18f-re	8431053427	m6 mm	3/8 inch	6 ft lb	13 ft lb	780 r/min	3.5 lb	466 mm	20 mm	19 cfm	10 mm	1/4 inch	76 db(a)	iso15744		iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd48 r65f-re	8431063717	m10 mm	1/2 inch	20 ft lb	48 ft lb	400 r/min	7.7 lb	700 mm	30 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	95 db(a)
ltd38 r32f-re	8431053591	m8 mm	1/2 inch	13 ft lb	24 ft lb	560 r/min	5.5 lb	546 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd28 r20f-re	8431053437	m6-8 mm	3/8 inch	7 ft lb	15 ft lb	570 r/min	3.7 lb	491 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r16f-rr	8431070386	m6 mm	3/8 inch	6 ft lb	12 ft lb	620 r/min	3.7 lb	421 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r20-rr	8431070383	m6-8 mm	3/8 inch	7 ft lb	15 ft lb	520 r/min	2.9 lb	313 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd13 r05-rr	8431053305	m3-5 mm	1/4 inch	1.1 ft lb	3.7 ft lb	850 r/min	1.6 lb	197 mm	16 mm	15 cfm	8 mm	1/8 inch	77 db(a)	iso15744		iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r38f-rr	8431070434	m8-10 mm	1/2 inch	14 ft lb	28 ft lb	480 r/min	5.5 lb	482 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd13 r04-rr	8431053304	m3-5 mm	1/4 inch	1.1 ft lb	3.7 ft lb	850 r/min	1.6 lb	197 mm	16 mm	15 cfm	8 mm	1/8 inch	77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r16f-re	8431053485	m6 mm	3/8 inch	6 ft lb	12 ft lb	620 r/min	3.7 lb	491 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd48 r81-rr	8431070448	m12 mm	1/2 inch	24 ft lb	60 ft lb	330 r/min	7.7 lb	410 mm	28 mm	63 cfm	12.5/16 mm		80 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r27f-rr	8431070430	m8 mm	1/2 inch	10 ft lb	20 ft lb	670 r/min	5.5 lb	482 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r8-re	8431053461	m5-6 mm	3/8 inch	2 ft lb	6 ft lb	1100 r/min	2.6 lb	363 mm	20 mm	17 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 r8f-rr	8431070384	m5-6 mm	3/8 inch	2 ft lb	6 ft lb	1100 r/min	3.5 lb	401 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 n55-re	8431053520	m10 mm	1/2 inch	20 ft lb	40 ft lb	470 r/min	4.8 lb	487 mm	20 mm	42 cfm	10 mm	1/4 inch	79 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd28 n18-re	8431053408	m6 mm	3/8 inch	6 ft lb	13 ft lb	780 r/min	2.6 lb	358 mm	20 mm	19 cfm	10 mm	1/4 inch	76 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r38-rr	8431070426	m8-10 mm	1/2 inch	14 ft lb	28 ft lb	480 r/min	4.6 lb	377 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd48 r81f-rr	8431070452	m12 mm	1/2 inch	24 ft lb	60 ft lb	330 r/min	8.2 lb	522 mm	28 mm	63 cfm	12.5/16 mm		80 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd48 r65-rr	8431070446	m10 mm	1/2 inch	20 ft lb	48 ft lb	400 r/min	7.7 lb	410 mm	28 mm	63 cfm	12.5/16 mm		80 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd13 r08-rr	8431053306	m3-5 mm	1/4 inch	1.1 ft lb	6 ft lb	500 r/min	1.7 lb	197 mm	16 mm	15 cfm	8 mm	1/8 inch	77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r32-rr	8431070424	m8 mm	1/2 inch	13 ft lb	24 ft lb	560 r/min	4.6 lb	377 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r47f-re	8431053599	m8-10 mm	1/2 inch	16 ft lb	35 ft lb	380 r/min	5.9 lb	625 mm	23 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd38 r27-rr	8431070422	m8 mm	1/2 inch	10 ft lb	20 ft lb	670 r/min	4.6 lb	377 mm	21 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd38 r47-re	8431053583	m8-10 mm	1/2 inch	16 ft lb	35 ft lb	380 r/min	5.1 lb	513 mm	20 mm	42 cfm	10 mm	1/4 inch	82 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec	93 db(a)
ltd38 r34-atex	8431053420					280 r/min	5.1 lb	513 mm					82 db(a)	iso15744	yes	en 13463-1:2009, iso 11148-6	100 psig	yes		2006/42/ec, 2014/34/eu		yes	ex ii 3 gd iib 135°c (t4)
ltd38 r47f-rr	8431070436	m8-10 mm	1/2 inch	16 ft lb	35 ft lb	380 r/min	5.9 lb	566 mm	23 mm	34 cfm	10/16 mm		77 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
ltd29 r14-atex	8431063162					900 r/min	1.5 kg	284 mm		21 cfm	10 mm	1/4 inch	80 db(a)	iso15744	yes	en 13463-1:2009, iso 11148-6	100 psig	yes	3 db(a)	2006/42/ec, 2014/34/eu		yes	ex ii 3 gd iib 135°c (t4)
ltd28 r16-rr	8431070382	m6 mm	3/8 inch	6 ft lb	12 ft lb	610 r/min	2.9 lb	313 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6	100 psi	yes		2006/42/ec
ltd28 r20f-rr	8431070388	m6-8 mm	3/8 inch	7 ft lb	15 ft lb	570 r/min	3.7 lb	421 mm	20 mm	17 cfm	10/13 mm		<70 db(a)	iso15744	yes	iso 11148-6	100 psi	yes	3 db(a)	2006/42/ec
