所属品牌：阿特拉斯·科普柯atlas copco

产品型号：ltv28/38/48

atlas阿特拉斯ltv28/38/48角向螺帽扳手，具有高速度以及精准度高的优点，可以实现准确快速的拧紧工作，同时这款atlas螺帽扳手采用了人体工程学设计，轻巧耐用以及极低的反作用力，易上手可以获得不错的生产效益。

商品描述
商品询价热度

阿特拉斯atlas扳手ltv28/38/48

在狭窄空间中有良好的可达性

可靠性高

持续高精度

高扭矩精度

强大的马达

螺旋切角齿轮

由于重量轻，舒适操作

专为高速和小尺寸而设计

容易扭转

atlas气动角向螺帽扳手ltv各型号参数

型号	id订货号	螺栓尺寸	方头驱动器	扭矩范围软接头值>	扭矩范围软接头值<	空载速度	重量	长度	角头高度	角中心到一边	空转速度下的空气消耗量	推荐的软管尺寸	进气口螺纹	声压	声音标准	声音不确定度	震动标准	震动值	经过 eac 认证	ec 标准	工作压力<	型号类型	断气式	eu 指令	ford 认证	可反转	声功率	atex	atex 代码	front part interface	套筒尺寸
ltv38 r42-10	8431060355	m8 mm	3/8 inch	15 ft lb	31 ft lb	400 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n10/11 tr	yes	93 db(a)
ltv38 n68-13	8431060248	m10 mm	1/2 inch	22 ft lb	40 ft lb	370 r/min	4.4 lb	427 mm	41 mm	20 mm	42 cfm	10 mm	1/4 inch	78 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv38 r42-13	8431060369	m8 mm	1/2 inch	15 ft lb	31 ft lb	400 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n11 tr	yes	93 db(a)
ltv28 r12-10	8431060163	m6 mm	3/8 inch	4 ft lb	9 ft lb	800 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv48 r200-l13	8431053498	m14 mm	1/2 inch	85 ft lb	148 ft lb	100 r/min	8.3 lb	610 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	95 db(a)
ltv48 r200-85-atex	8431053491	m14 mm	1/2 inch	85 ft lb	150 ft lb	80 r/min	8.3 lb	610 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	>2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	95 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv38 r85-170-atex	8431060343	m10-12 mm	1/2 inch	29 ft lb	61 ft lb	150 r/min	6.1 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv38 r57-13	8431060351	m10 mm	1/2 inch	22 ft lb	41 ft lb	280 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n12 tr	yes	93 db(a)
ltv28 r28f-rr	8431060197	m8 mm	3/8 inch	10 ft lb	21 ft lb	340 r/min	4.0 lb	300 mm	150 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n9 tr	yes
ltv38 n55-10	8431060214	m10 mm	3/8 inch	22 ft lb	40 ft lb	440 r/min	4.0 lb	410 mm	34.5 mm	18 mm	42 cfm	10 mm	1/4 inch	78 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv28 n28-10	8431060084	m8 mm	3/8 inch	10 ft lb	21 ft lb	500 r/min	2.9 lb	325 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv28 r15-10	8431060155	m6 mm	3/8 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv38 r50-atex	8431060348	m10 mm	3/8 inch	18 ft lb	36 ft lb	330 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv38 r50 had	8431060382	m10 mm		18 ft lb	36 ft lb	360 r/min	4.8 lb	453 mm	41 mm	20 mm	16 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n11 tr	yes	93 db(a)			50 had
ltv38 r160-atex	8431060373	m12 mm	1/2 inch	40 ft lb	118 ft lb	100 r/min	7.2 lb	500 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv38 r70-13	8431060346	m10 mm	1/2 inch	24 ft lb	50 ft lb	225 r/min	5.3 lb	487 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n12/13 tr	yes	93 db(a)
ltv38 r50-13	8431060371	m10 mm	1/2 inch	18 ft lb	36 ft lb	330 r/min	4.8 lb	453 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	93 db(a)
ltv38 r65-atex	8431060111	m12 mm	1/2 inch	20 ft lb	48 ft lb	120 r/min	5.7 lb	465 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv28 r28-120	8431060135	m8 mm	3/8 inch	5 ft lb	21 ft lb	120 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv48 r120-l13	8431053488	m12 mm	1/2 inch	51 ft lb	88 ft lb	215 r/min	7.6 lb	590 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n14/15 tr	yes	95 db(a)
ltv28 n15-10	8431060099	m6 mm	3/8 inch	5 ft lb	11 ft lb	950 r/min	2.6 lb	305 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv48 r150-fs	8431061017	m12 mm		44 ft lb	111 ft lb	180 r/min	7.6 lb	590 mm	70 mm	25 mm	59 cfm	12.7 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	95 db(a)			200 fs	19 mm
ltv38 r85-13	8431060338	m10-12 mm	1/2 inch	29 ft lb	61 ft lb	190 r/min	6.1 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n14 tr	yes	93 db(a)
ltv38 r42 had	8431060375	m8 mm		15 ft lb	31 ft lb	430 r/min	4.8 lb	453 mm	41 mm	20 mm	16 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n10/11 tr	yes	93 db(a)			50 had
ltv38 r85-had	8431060958	m10-12 mm		30 ft lb	67 ft lb	210 r/min	6.5 lb	530 mm	52 mm	25 mm	16 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n14 tr	yes	93 db(a)			200 had
ltv28 r28-42	8431060144	m8 mm	1/4 inch	10 ft lb	21 ft lb	340 r/min	3.1 lb	390 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744		iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv28 r07-6	8431060165	m5 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv28 rl28-10	8431060133	m8 mm	3/8 inch	10 ft lb	21 ft lb	80 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv38 n45-10	8431060206	m8 mm	3/8 inch	16 ft lb	33 ft lb	520 r/min	4.0 lb	410 mm	34.5 mm	18 mm	42 cfm	10 mm	1/4 inch	78 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n11 tr	no
ltv28 r20-10	8431060150	m6 mm	3/8 inch	7 ft lb	15 ft lb	530 r/min	3.1 lb	355 mm	34.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n6/7/8 tr	yes
ltv28 r28-10	8431060140	m8 mm	3/8 inch	10 ft lb	21 ft lb	340 r/min	3.1 lb	350 mm	29.5 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n9 tr	yes
ltv38 r40-lt-had	8431060952	m8-10 mm		11 ft lb	30 ft lb	210 r/min	6.5 lb	530 mm	52 mm	25 mm	16 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	93 db(a)			200 had
ltv48 r150-l13	8431053493	m12 mm	1/2 inch	51 ft lb	111 ft lb	170 r/min	7.6 lb	590 mm	52 mm	25 mm	59 cfm	12.5 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	95 db(a)
ltv38 r91-atex	8431060345	m10-12 mm	1/2 inch	29 ft lb	67 ft lb	140 r/min	6.5 lb	530 mm	52 mm	25 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv28 r07-42	8431060173	m5 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv28 r20-42	8431060148	m6 mm	1/4 inch	7 ft lb	15 ft lb	420 r/min	3.1 lb	350 mm	34 mm	13.5 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv38 n85-13	8431060252	m10 mm	1/2 inch	29 ft lb	63 ft lb	300 r/min	4.8 lb	460 mm	41 mm	20 mm	42 cfm	10 mm	1/4 inch	78 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv38 r70-140-atex	8431060356	m10 mm	1/2 inch	20 ft lb	50 ft lb	120 r/min	5.3 lb	500 mm	41 mm	20 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv38 r50-175-atex	8431060353	m8 mm	3/8 inch	15 ft lb	36 ft lb	175 r/min	4.8 lb	448 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	en 13463-1:2009, iso 11148-6	100 psig	angle	yes	2006/42/ec, 2014/34/eu		yes	93 db(a)	yes	ex ii 3 gd iib 135°c (t4)
ltv48 r200-fs	8431061021	m14 mm		85 ft lb	148 ft lb	100 r/min	8.3 lb	610 mm	70 mm	25 mm	59 cfm	12.8 mm	1/2 inch	84 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	95 db(a)			200 fs	19 mm
ltv38 n31-10	8431060204	m8 mm	3/8 inch	13 ft lb	23 ft lb	800 r/min	3.7 lb	400 mm	34.5 mm	13.5 mm	42 cfm	10 mm	1/4 inch	78 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n9/10 tr	no
ltv28 n30-10	8431060081	m8 mm	3/8 inch	11 ft lb	22 ft lb	400 r/min	2.9 lb	325 mm	29.5 mm	13.5 mm	23 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		no
ltv28 r07-q	8431060168	m6 mm	1/4 inch	1.8 ft lb	5 ft lb	1100 r/min	2.9 lb	334 mm	28.5 mm	10 mm	17 cfm	8 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv28 r15-6	8431060152	m6 mm	1/4 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
ltv38 r50-10	8431060363	m10 mm	3/8 inch	18 ft lb	36 ft lb	330 r/min	4.4 lb	436 mm	34.5 mm	18 mm	34 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec	ca n11 tr	yes	93 db(a)
ltv38 r65-fs	8431060987	m12 mm		25 ft lb	48 ft lb	280 r/min	5.7 lb	515 mm	53 mm	20 mm	38 cfm	10 mm	1/4 inch	82 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes	93 db(a)				16 mm
ltv28 r15-q	8431060153	m6 mm	1/4 inch	5 ft lb	11 ft lb	560 r/min	3.1 lb	349 mm	28 mm	11 mm	21 cfm	10 mm	1/4 inch	76 db(a)	iso15744	3 db(a)	iso28927-2	<2.5 m/s²	yes	iso 11148-6	100 psig	angle	yes	2006/42/ec		yes
