所属品牌：阿特拉斯·科普柯atlas copco
产品型号：smartqic/nip
smartqic联轴器是一款具有高气流性能的单手操作联轴器。它适用于多种类型的应用和气动工具；如螺丝刀、组装工具、钻机和打磨机。它坚固耐用，由镀锌钢/黄铜制成。采用独特的安全通风设计，在其能够断开之前将空气排出，从而大限度地降低操作员受伤的风险。
- 商品描述
- 商品询价热度
atlas阿特拉斯smartqic联轴器
阿特拉斯smartqic联轴器
连接力小
更长的寿命
大流量联轴器
更低的噪音水平
可靠性高，压降低
经久耐用，操作简单
带排气接头的安全功能
符合人体工学，采用无泄漏设计
有效的减少软管缠绕和对操作员的伤害
符合 en 983 / iso 4414 的安全特性
atlas smartqic联轴器各型号技术参数
| 型号 | id | 连接 | 螺纹尺寸 | 工作压力 | 工作温度 | 工作温度 | 流量 (0.5 bar δp) | 流量 (7 psi δp) | 软管尺寸 |
|---|---|---|---|---|---|---|---|---|---|
| smartqic-15us-m10-npt | 4221004003 | male | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| nip-10us-f15 | 4221005111 | female | 1/2 bsp | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10us-f10 | 4221005110 | female | 3/8 bsp | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-10us-f15-npt | 4221005009 | female | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10a-m06 | 4221006104 | male | 1/4 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| smartqic-10a-f06 | 4221006006 | female | 1/4 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| smartqic-10us-h10 | 4221005000 | hose | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | 3/2 inch | |
| nip-10us-m10 | 4221005104 | male | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-15us-h10 | 4221004100 | hose | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | 3/8 inch | |
| smartqic-10us-h13 | 4221005001 | hose | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | 1/2 inch | |
| smartqic-10a-h08 | 4221006001 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 9/32 inch | |
| smartqic-10a-m10 | 4221006004 | male | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10us-h10 | 4221005101 | hose | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | 3/8 inch | |
| nip-10us-m10-npt | 4221005107 | male | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10us-h13 | 4221005102 | hose | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | 1/2 inch | |
| nip-10a-m15 | 4221006106 | male | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10a-f10 | 4221006108 | female | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-15us-m15-npt | 4221004105 | male | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| nip-10a-h06 | 4221006100 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 1/4 inch | |
| smartqic-10a-m15 | 4221006005 | male | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| smartqic-15us-f20-npt | 4221004008 | female | 3/4 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| nip-10a-f06 | 4221006107 | female | 1/4 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| smartqic-10us-f10-npt | 4221005008 | female | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10a-h13 | 4221006103 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 1/2 inch | |
| smartqic-15us-f15-npt | 4221004007 | female | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| smartqic-10us-f10 | 4221005006 | female | 3/8 bsp | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10us-f06 | 4221005109 | female | 1/4 bsp | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-15us-m15-npt | 4221004004 | male | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| nip-15us-f10-npt | 4221004107 | female | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| nip-10us-m06 | 4221005103 | male | 1/4 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-15us-f20-npt | 4221004109 | female | 3/4 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| smartqic-10a-h10 | 4221006002 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 3/8 inch | |
| nip-15us-h20 | 4221004103 | hose | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | 3/4 inch | |
| smartqic-10us-m15 | 4221005003 | male | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-15us-m20-npt | 4221004005 | male | 3/4 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| smartqic-15us-h20 | 4221004002 | hose | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | 3/4 inch | |
| smartqic-10us-f15 | 4221005007 | female | 1/2 bsp | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-10a-f15 | 4221006008 | female | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10a-h10 | 4221006102 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 3/8 inch | |
| nip-15us-m10-npt | 4221004104 | male | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| nip-15us-f15-npt | 4221004108 | female | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| smartqic-10us-m10-npt | 4221005004 | male | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-10a-f10 | 4221006007 | female | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10us-m15 | 4221005105 | male | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10a-h08 | 4221006101 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 9/32 inch | |
| smartqic-15us-f10-npt | 4221004006 | female | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | |
| nip-10us-f06-npt | 4221005112 | female | 1/4 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10a-f15 | 4221006109 | female | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10us-f10-npt | 4221005113 | female | 3/8 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-10a-h06 | 4221006000 | hose | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | 1/4 inch | |
| smartqic-10us-m10 | 4221005002 | male | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-15us-m20-npt | 4221004106 | male | 3/4 npt | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | |
| smartqic-10a-m06 | 4221006003 | male | 1/4 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10a-m10 | 4221006105 | male | 3/8 bspt | 232 psi | -4.0 °f | 212.0 °f | 33 l/s | 70 cfm | |
| nip-10us-m15-npt | 4221005108 | male | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-10us-m15-npt | 4221005005 | male | 1/2 bspt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| smartqic-15us-h13 | 4221004000 | hose | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 146 cfm | 1/2 inch | |
| nip-10us-h08 | 4221005100 | hose | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | 5/16 inch | |
| nip-15us-h13 | 4221004101 | hose | 232 psi | -4.0 °f | 212.0 °f | 69 l/s | 147 cfm | 1/2 inch | |
| nip-10us-f15-npt | 4221005114 | female | 1/2 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm | |
| nip-10us-m06-npt | 4221005106 | male | 1/4 npt | 232 psi | -4.0 °f | 212.0 °f | 42 l/s | 90 cfm |
