所属品牌：阿特拉斯·科普柯atlas copco

产品型号：ergoqic系列

atlas 阿特拉斯是一款结实耐用的全流式快接头，并且对快接头内部的空气没有限制。ergoqic 具有安全功能的球阀联轴器，可以提供大的空气流量,采用ergoqic升级空气系统，都可提高作业效率和能源效率。适用于大多数装配工具、钻机和磨床，设计采用小压降，以减少能源消耗。联轴器采用硬化钢制成，无泄漏设计，使用寿命长，适用于大负荷应用。

商品描述
商品询价热度

atlas阿特拉斯ergoqic安全联轴器

atlas ergoqic<b style=

阿特拉斯ergoqic安全联轴器优势特点

全流连接

坚固耐用

节能

使用寿命长

无气流限制

操作方便快捷，工具更换方便。

人体工学设计，体积小，重量轻

由于高空气流量和压力而提高作业效率

atlas ergoqic安全联轴器各型号技术参数

型号	id	连接	螺纹尺寸	工作压力	流量 (0.5 bar δp)	流量 (7 psi δp)	软管尺寸
ergoqic-08-m08u	8202111509	male	1/4 npt	230 psi	30 l/s	64 cfm
ergoqic-08e-h13	8202110603	hose		230 psi	38 l/s	80 cfm	1/2 inch
ergoqic-15e-m10	8202110660	male	3/8 bsp	230 psi	76 l/s	161 cfm
ergoqic-08e-h10	8202110602	hose		230 psi	38 l/s	80 cfm	3/8 inch
ergoqic-10-f08	8202112100	female	1/4 bsp	230 psi	60 l/s	128 cfm
ergoqic-10-m10u	8202112515	male	3/8 npt	230 psi	65 l/s	138 cfm
ergoqic-08us-m10	8202110307	male	3/8 bsp	230 psi	17 l/s	35 cfm
ergoqic-10us-m15	8202110711	male	1/2 bsp	230 psi	43 l/s	90 cfm
ergoqic-15e-h13	8202110651	hose		230 psi	76 l/s	161 cfm	1/2 inch
ergoqic-08us-h06	8202110300	hose		230 psi	17 l/s	35 cfm	1/4 inch
ergoqic-08-f08	8202111090	female	1/4 bsp	230 psi	29 l/s	61 cfm
ergoqic-15us-m10u	8202110808	male	3/8 npt	230 psi	72 l/s	153 cfm
ergoqic-08us-f10u	8202110312	female	3/8 npt	230 psi	14 l/s	30 cfm
ergoqic-10-f10u	8202112535	female	3/8 npt	230 psi	65 l/s	138 cfm
ergoqic-10us-h20	8202110705	hose		230 psi	43 l/s	90 cfm	3/4 inch
ergoqic-15us-m10	8202110809	male	3/8 bsp	230 psi	77 l/s	162 cfm
ergoqic-08-f10u	8202111535	female	3/8 npt	230 psi	30 l/s	64 cfm
ergoqic-10us-f15u	8202110716	female	1/2 npt	230 psi	33 l/s	70 cfm
ergoqic-10us-f08	8202110713	female	1/4 bsp	230 psi	43 l/s	90 cfm
ergoqic-08-m15u	8202111525	male	1/2 npt	230 psi	30 l/s	64 cfm
ergoqic-08e-m08	8202110604	male	1/4 bsp	230 psi	38 l/s	80 cfm
ergoqic-10-asia-ft08	8202110409	female	1/4 bspt	230 psi	35 l/s	73 cfm
ergoqic-15us-m15u	8202110810	male	1/2 npt	230 psi	72 l/s	153 cfm
ergoqic-15us-m15	8202110811	male	1/2 bsp	230 psi	77 l/s	162 cfm
ergoqic-08-h08	8202111012	hose		230 psi	29 l/s	61 cfm	5/16 inch
ergoqic-15us-h13	8202110803	hose		230 psi	77 l/s	162 cfm	1/2 inch
ergoqic-10us-f10u	8202110714	female	3/8 npt	230 psi	33 l/s	70 cfm
ergoqic-08-m10u	8202111517	male	3/8 npt	230 psi	30 l/s	64 cfm
ergoqic-10-asia-ft10	8202110410	female	3/8 bspt	230 psi	35 l/s	73 cfm
ergoqic-10us-f15	8202110717	female	1/2 bsp	230 psi	43 l/s	90 cfm
ergoqic-10us-h13	8202110703	hose		230 psi	43 l/s	90 cfm	1/2 inch
ergoqic-15us-h20	8202110805	hose		230 psi	77 l/s	162 cfm	3/4 inch
ergoqic-15e-h20	8202110653	hose		230 psi	76 l/s	161 cfm	3/4 inch
ergoqic-08us-f10	8202110313	female	3/8 bsp	230 psi	17 l/s	35 cfm
ergoqic-10us-m10u	8202110708	male	3/8 npt	230 psi	33 l/s	70 cfm
ergoqic-10-f15	8202112110	female	1/2 bsp	230 psi	60 l/s	128 cfm
ergoqic-08us-h10	8202110302	hose		230 psi	17 l/s	35 cfm	3/8 inch
ergoqic-10-asia-mt10	8202110406	male	3/8 bspt	230 psi	35 l/s	73 cfm
ergoqic-10-h08	8202112040	hose		230 psi	60 l/s	128 cfm	5/16 inch
ergoqic-10-m25	8202112099	male	1 bsp	230 psi	60 l/s	128 cfm
ergoqic-10-m08	8202112085	male	1/4 bsp	230 psi	60 l/s	128 cfm
ergoqic-08us-m08u	8202110304	male	1/4 npt	230 psi	14 l/s	30 cfm
ergoqic-10us-f10	8202110715	female	3/8 bsp	230 psi	43 l/s	90 cfm
ergoqic-15e-m15	8202110661	male	1/2 bsp	230 psi	76 l/s	161 cfm
ergoqic-10-m15	8202112097	male	1/2 bsp	230 psi	60 l/s	128 cfm
ergoqic-15us-f10	8202110815	female	3/8 bsp	230 psi	77 l/s	162 cfm
ergoqic-10us-m15u	8202110710	male	1/2 npt	230 psi	33 l/s	70 cfm
ergoqic-08e-m10	8202110605	male	3/8 bsp	230 psi	38 l/s	80 cfm
ergoqic-08-h06	8202111004	hose		230 psi	29 l/s	61 cfm	1/4 inch
ergoqic-10-f10	8202112105	female	3/8 bsp	230 psi	60 l/s	128 cfm
ergoqic-10-h06	8202112030	hose		230 psi	60 l/s	128 cfm	1/4 inch
ergoqic-10-asia-mt08	8202110405	male	1/4 bspt	230 psi	35 l/s	73 cfm
ergoqic-15us-f10u	8202110814	female	3/8 npt	230 psi	72 l/s	153 cfm
ergoqic-08us-m08	8202110305	male	1/4 bsp	230 psi	17 l/s	35 cfm
ergoqic-08-h13	8202111040	hose		230 psi	29 l/s	61 cfm	1/2 inch
ergoqic-15e-f15	8202110671	female	1/2 bsp	230 psi	76 l/s	161 cfm
ergoqic-08us-f08	8202110311	female	1/4 bsp	230 psi	17 l/s	35 cfm
ergoqic 08e h10	8202110612	hose		230 psi	38 l/s	80 cfm	3/8 inch
ergoqic-10-m20	8202112098	male	3/4 bsp	230 psi	60 l/s	128 cfm
ergoqic-08us-h08	8202110301	hose		230 psi	17 l/s	35 cfm	5/16 inch
ergoqic-10-asia-h13	8202110403	hose		230 psi	35 l/s	73 cfm	1/2 inch
ergoqic-10-m15u	8202112523	male	1/2 npt	230 psi	65 l/s	138 cfm
ergoqic-10-asia-h10	8202110402	hose		230 psi	35 l/s	73 cfm	3/8 inch
ergoqic-08e-f10	8202110608	female	3/8 bsp	230 psi	38 l/s	80 cfm
ergoqic-08us-m10u	8202110306	male	3/8 npt	230 psi	14 l/s	30 cfm
ergoqic-10-m10	8202112093	male	3/8 bsp	230 psi	60 l/s	128 cfm
ergoqic-15e-h16	8202110652	hose		230 psi	76 l/s	161 cfm	5/8 inch
ergoqic-15e-m20	8202110662	male	3/4 bsp	230 psi	76 l/s	161 cfm
ergoqic-10-asia-ft15	8202110411	female	1/2 bspt	230 psi	35 l/s	73 cfm
ergoqic-10us-h10	8202110702	hose		230 psi	43 l/s	90 cfm	3/8 inch
ergoqic-15us-h16	8202110804	hose		230 psi	77 l/s	162 cfm	5/8 inch
ergoqic-08-m10	8202111079	male	3/8 bsp	230 psi	29 l/s	61 cfm
ergoqic-08e-h08	8202110601	hose		230 psi	38 l/s	80 cfm	5/16 inch
ergoqic-08-h10	8202111038	hose		230 psi	29 l/s	61 cfm	3/8 inch
ergoqic-15e-f10	8202110670	female	3/8 bsp	230 psi	76 l/s	161 cfm
ergoqic-08e-m15	8202110606	male	1/2 bsp	230 psi	38 l/s	80 cfm
ergoqic-10us-m08u	8202110706	male	1/4 npt	230 psi	33 l/s	70 cfm
ergoqic-15us-h10	8202110802	hose		230 psi	77 l/s	162 cfm	3/8 inch
ergoqic-08us-f08u	8202110310	female	1/4 npt	230 psi	14 l/s	30 cfm
ergoqic-08us-m15	8202110309	male	1/2 bsp	230 psi	17 l/s	35 cfm
ergoqic-08e-f15	8202110609	female	1/2 bsp	230 psi	38 l/s	80 cfm
ergoqic-10-h16	8202112050	hose		230 psi	60 l/s	128 cfm	5/8 inch
ergoqic-08-f10	8202111095	female	3/8 bsp	230 psi	29 l/s	61 cfm
ergoqic-10-m08u	8202112507	male	1/4 npt	230 psi	65 l/s	138 cfm
ergoqic-10-h20	8202112060	hose		230 psi	60 l/s	128 cfm	3/4 inch
ergoqic-10-asia-mt15	8202110407	male	1/2 bspt	230 psi	35 l/s	73 cfm
ergoqic-08e-f08	8202110607	female	1/4 bsp	230 psi	38 l/s	80 cfm
ergoqic-10-h10	8202112002	hose		230 psi	60 l/s	128 cfm	3/8 inch
ergoqic-10us-f08u	8202110712	female	1/4 npt	230 psi	33 l/s	70 cfm
ergoqic-10us-m10	8202110709	male	3/8 bsp	230 psi	43 l/s	90 cfm
ergoqic-08us-m15u	8202110308	male	1/2 npt	230 psi	14 l/s	30 cfm
ergoqic-10-f08u	8202112530	female	1/4 npt	230 psi	65 l/s	138 cfm
ergoqic-08-m08	8202111061	male	1/4 bsp	230 psi	29 l/s	61 cfm
ergoqic-10-asia-h06	8202110400	hose		230 psi	35 l/s	73 cfm	1/4 inch
ergoqic-08e-h06	8202110600	hose		230 psi	38 l/s	80 cfm	1/4 inch
ergoqic-08-m15	8202111087	male	1/2 bsp	230 psi	29 l/s	61 cfm
ergoqic-10us-h16	8202110704	hose		230 psi	43 l/s	90 cfm	5/8 inch
ergoqic-08-f08u	8202111530	female	1/4 npt	230 psi	30 l/s	64 cfm
ergoqic-15us-f15	8202110817	female	1/2 bsp	230 psi	77 l/s	162 cfm
ergoqic-15us-f15u	8202110816	female	1/2 npt	230 psi	72 l/s	153 cfm
ergoqic-10-h13	8202112010	hose		230 psi	60 l/s	128 cfm	1/2 inch
ergoqic-10-asia-h08	8202110401	hose		230 psi	35 l/s	73 cfm	5/16 inch
ergoqic-10us-m08	8202110707	male	1/4 bsp	230 psi	43 l/s	90 cfm
